Piston Valves
Reliable, low-maintenance steam isolation
Piston Valves
Overview
Piston valves provide durable isolation and regulation, particularly on steam and condensate. Sealing rings around a precision piston give long-life, drip-tight shut-off with the ability to re-seal by simply tightening the gland.
Key Features
- Long-life sealing rings, drip-tight shut-off
- Ideal for steam and condensate
- Re-sealable by gland adjustment
- Robust, simple construction
- Low maintenance over long service life
Applications
Steam systems Condensate Heating Power General utilities
Technical Data
| Size Range | 1/2" – 10" (DN15 – DN250) |
|---|---|
| Pressure Class | PN16 – PN40 / Class 150 – 300 |
| Body Materials | Cast iron, WCB, CF8 (SS304), CF8M (SS316) |
| Trim / Internals | Graphite / PTFE sealing rings |
| End Connections | Flanged, Screwed |
| Operation | Handwheel |
| Standards | BS / DIN / ANSI B16.34, IBR approved |
Full datasheet available on request
Types & Configurations
Available in the following designs — each can be tailored to your specification.
