Knife Gate Valves
Overview
Knife gate valves are purpose-built for thick, fibrous and abrasive media. A sharp-edged gate cuts through slurry to give clean isolation in a compact, lightweight body — widely used in pulp & paper, mining, sugar and effluent applications.
Key Features
- Cuts through slurry, fibre and bulk solids
- Compact, lightweight wafer body
- Uni- and bi-directional designs
- Manual, gear or pneumatic operation
- Replaceable seat and gland packing
Applications
Pulp & paper Mining Sugar Effluent / wastewater Cement
Technical Data
| Size Range | 2" – 40" (DN50 – DN1000) |
|---|---|
| Pressure Class | PN10 / PN16 / Class 150 |
| Body Materials | Cast iron, Ductile iron, CF8 (SS304), CF8M (SS316) |
| Trim / Internals | SS304 / SS316 gate, EPDM / NBR / PTFE seat |
| End Connections | Wafer, Lugged, Flanged |
| Operation | Handwheel, Gear, Pneumatic cylinder |
| Standards | MSS SP-81 / EN 593 |
Full datasheet available on request
Types & Configurations
Available in the following designs — each can be tailored to your specification.
